WORLD UNIQUEEN WU-831-DIN-RJ45 DIN Rail 1-Channel Constant Voltage DMX Decoder
$54.95
SEND US A MESSAGE
CONTACT INFORMATION
Your personal data will be used to process your enquiry, support your experience throughout this website, and for other purposes described in our privacy policy.
The WORLD UNIQUEEN WU Series Decoders are specifically developed for constant voltage LED lamps.
Description
The WORLD UNIQUEEN WU-831-DIN-RJ45 carries an advanced micro-computer control technology that is able to convert and transfer standard DMX512/1990 signal to PWM signal. In addition, this device features 1 output channel (Max Load Current: 10A).
This device can be used as DMX512 master or as DMX decoder to connect a computerised digital output console with an analog silicon case, plus it controls LED lamps of architecture and generic lighting.
Features
- Automatically adapts input voltage: DC12V-24V.
- Input: Standard DMX512 signal; 3-digital-display shows DMX address code.
- 1 channel output; logarithmic dimming; lamplight soft & stable without strobe flash.
- DMX Master mode & slave mode available.
- 8 colour changing modes and 10 speed scales are built-in.
- Indicator of the DMX512 signal receiving status.
- Power loss memory function.
- Wrong wiring protection at DMX port + over current protection and short circuit protection.
- The DIN rail style design facilitates the installation of large-scale projects.
TECHNICAL DOC.
| WORLD UNIQUEEN WU-831-DIN-RJ45 DIN Rail 1-Channel Constant Voltage DMX Decoder Manual | ||
|---|---|---|
| WORLD UNIQUEEN WU-831-DIN-RJ45 DIN Rail 1-Channel Constant Voltage DMX Decoder Manual | 735.05 KB |
